Smart Level 2 EV Charger 16Amp Charging Point Charging Station
LEVEL 2 FAST CHARGER FOR RESIDENTIAL
Green Science Home Level 2 EV Charging Station - Available with NEMA 14-50 Plug or NEMA 6-50 Plug or Hardwired
- Fit all EVs and PHEVS:
- Green Science NEMA 14-50 Plug or NEMA 6-50 pLUG is a simple, powerful, heavy-duty and portable Electric Vehicle Charging Station which is suitable for normal and cold weather.
- Compatible with all EVs and PHEVs sold in North America.
- Safe and Reliable :
- Manufacturerd according to UL standard.
- IK08 and IP65 (Water resistant), Fire resistant.
- Over Current, Over Voltage, Under Voltage, Missing Diode, Ground Fault, and Over Temperature Protections.
- Smart App Control :
- More power and output configurations by Smart Life App.
- Users can adjust the current through the app, set the timing of charging, view the history of charging records and other operations.
- Easy to install and use:
- Save hundreds of dollars on installation – just install a simple 14-50R outlet and you are ready to plug in your EV Charger. Easily transportable. Simple to remove from the mounting bracket and transport between different locations. NEMA-4 water and air tight PC enclosure.
The Flexibility to Work with Any Home
A wall outlet just doesn't cut it, a flexible home charger that can deliver 48 amps Max of power.
Works with Any EV
It uses a universal SAE J1772 connector and has been tested with al top-selling models: Chevrolet Bolt EV, Chevy Volt, Hyundai Kona, Kia Niro, Nissan LEAF, Tesla, Toyota Prius Prime and more.
Wall-mounted or Pedestal-mounted
According to different user conditions, there are different installation methods, if it is commercial, you can choose to install on the column, unified and beautiful, if it is home, you can choose to install on the wall, convenient, of course, the home can also choose to install on the column, according to customer needs.
TECHNICAL DATA
| Model | GS-AC32-B01 | GS-AC40-B01 | GS-AC48-B01 |
| Power Supply | L1+L2+Ground | ||
| Rated Voltage | 240V AC Level 2 | ||
| Rated Current | 32A | 40A | 48A |
| Frequncy | 60Hz | 60Hz | 60Hz |
| Rated Power | 7.5kw | 10kw | 11.5kw |
| Charging Connector | SAE J1772 Type 1 | ||
| Cable Length | 11.48 ft.(3.5m) 16.4ft. (5m) or 24.6ft(7.5m) | ||
| Input Power Cable | NEMA 14-50 or NEMA 6-50 or Hardwired | ||
| Enclosure | PC 940A +ABS | ||
| Control Mode | Plug& Play /RFID Card/App | ||
| Emergency Stop | Yes | ||
| Internet | WIFI /Bluetooth/RJ45/4G (Optional) | ||
| Protocol | OCPP 1.6J | ||
| Energy Meter | Optional | ||
| IP Protection | NEMA Type 4 | ||
| RCD | CCID 20 | ||
| Impact Protection | IK10 | ||
| Electric Protection | Over Current Protection, Residual current protection, Ground Protection, Surge protection, Over/Under Voltage protection, Over/Under temperature protection |
||
| Certification | FCC | ||
| Manufactured Standard | SAE J1772, UL2231, and UL 2594 | ||
AC charging pile
Firstly, this product can accept customised gun head type so as to match all the trolley types on the market.
Secondly, it has reached the unified international certification standard for export to Europe, America and so on, and it can provide a 1-3 year warranty period.
Thirdly, it has reached the highest waterproof level of the charging pile, and it can support indoor or outdoor environment, and the working temperature is from -25℃ to 50℃.
Fourth, it can accept APP remote control operation charging, simple and easy to operate.
If you still want to know more please contact our official email, we have 24-hour human customer service for you.
